Xuan Nickel Alloys is a reliable factory and exporter in Da Nang, Vietnam, with expertise in producing high-quality steel and nickel alloys for various industries globally. Xuan Nickel Alloys supplies top-quality Manganese Bronze Sheets and Plates, which are renowned for their superior strength, durability, and resistance to corrosion. Designed for tough industrial and marine use, these sheets and plates deliver consistent performance even under tough conditions. Dedicated to precision, innovation, and customer satisfaction, Xuan Nickel Alloys guarantees that each product is up to stringent quality standards. Our Manganese Bronze Sheets and Plates are the business’s top choice for those in need of long-lasting, high-performance alloy solutions.
Manganese Bronze Sheets and Plates are copper-based alloys that have about 5% manganese, along with iron, aluminum, and trace elements. It increases the strength, wear resistance, and corrosion protection. The sheets, mechanically, have high tensile strength (600–800 MPa), superior toughness, and good machinability and thus can be used for heavy-duty applications. They have very good resistance to fatigue and seawater corrosion and retain their strength in harsh industrial and marine environments. The combination of mechanical robustness and corrosion resistance ensures long-term reliability and high performance, making Manganese Bronze Sheets and Plates ideal for precision engineering and structural applications.
| Standard | JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888, ASTM B19,ASTM B122,etc |
| Thickness | 0.1-120mm |
| Width | 2-2500mm |
| Length | 1m,2m,3m,6m,or as required |
| Surface | mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc |
| Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Application | Brass plate has a high corrosion resistance, and have good plasticity,in the air easy to cold and hot pressure processing,easy to welding, forging and tin, no stress corrosion cracking the tendency. |
| Cu(1) | Al | Fe | Pb | Mn | Sn | Zn | |
| Min./Max. | 57.0-60.0 | .25 | .8-2.0 | .20 | .05-.50 | .50-1.5 | Rem. |
| Nominal | 58.5 | – | 1.4 | – | .10 | 1.0 | 39.0 |
| ensile Strength, min | Yield Strength, at 0.5% extension under load, typ | Elongation, in 2 in. or 50 mm typ | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | |
| 65 | 448 | 25 | 172 | 20 | 90 | |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Manganese Bronze Sheets and Plates in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Manganese Bronze Sheets and Plates find wide usage in marine and industrial applications because of their strength, corrosion-resisting properties, and durability. In shipbuilding, they are widely used in propeller shafts, rudder parts, and hull fittings. They are used in automobile and heavy machinery industries for gears, engine components, bearings, valves, and pumps operating in severe conditions. Their superior wear and fatigue resistances qualify them for long-term reliability applications in structural parts. Manganese bronze is also employed in electrical equipment, precision instruments, and other industrial high-performance uses. Its durability and versatility render it invaluable in applications where durability and resistance to corrosion are essential.
