Xuan Nickel Alloys is a reputable manufacturer and supplier of Alloy C263 Sheets and Plates based in Da Nang, Vietnam. We pride ourselves on delivering top-notch materials designed for high-performance applications. Renowned for their exceptional high-temperature strength, corrosion resistance, and durability, Alloy C263 Sheets and Plates are essential in various critical industries. By strictly adhering to international standards, we ensure that our precision-engineered products offer reliability, performance, and a long service life. Whether it’s aerospace, power generation, chemical processing, or other demanding industrial environments, our Alloy C263 Sheets and Plates are the perfect choice.
These sheets and plates are made from a blend of nickel, cobalt, chromium, and molybdenum, with added titanium and aluminum for precipitation hardening. This unique composition provides remarkable resistance to high-temperature oxidation and corrosion. On the mechanical side, Alloy C263 boasts high tensile strength, excellent creep rupture strength, and impressive toughness, even at elevated temperatures. Its good formability, weldability, and long-lasting durability make it a go-to material for applications that demand strength, stability, and resistance in harsh environments.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Sheets and Plates in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Alloy C263 Sheets and Plates are widely used across industries where high strength and corrosion resistance are crucial. In aerospace, they play a vital role in turbine engines, combustion chambers, and afterburner components. In the power generation field, they are utilized in gas turbines, heat exchangers, and high-temperature structural parts. The chemical processing industry depends on them for reactors, vessels, and piping systems that face harsh chemicals. Additionally, marine and offshore engineering sectors rely on these sheets and plates for equipment that requires superior oxidation resistance. Their reliability under stress and extreme conditions makes Alloy C263 an indispensable choice for critical engineering applications.
