Xuan Nickel Alloys, a leading manufacturer and supplier in Da Nang, Vietnam, specializes in high-quality Titanium Tube Fittings. Renowned for their precision engineering, these fittings are designed to offer exceptional corrosion resistance and strength in demanding environments. Ideal for industries such as aerospace, chemical processing, and power generation, Xuan Nickel Alloys’ Titanium Tube Fittings ensure reliable performance and longevity. With a commitment to excellence and customer satisfaction, the company provides top-notch solutions to meet diverse industrial needs.
Titanium tube fittings are made of high purity titanium, usually in grades such as Gr 2, which provide excellent corrosion resistance, light weight and biocompatibility Their mechanical properties include 275-450 MPa tensile strength, ductility a height and density 4.51 g/cm The fitting can withstand extreme temperatures and is non-magnetic. Advantages include excellent resistance to seawater, chlorine and acidic environments, making them ideal for aerospace, marine and chemical applications Their lightweight nature also contributes to energy consumption work effectively in various systems.
| Specifications (ASTM/ASME) | ASTM B381/381M R56400, ASME SB381/381M R56400 |
| Tube Size | 1/16 OD to 2 OD, Od to 50mm OD |
| Types we Offer | Titanium Instrumentation Fittings Ti Grade 5 Double Ferrule Fittings Ti Grade 2 Twin Ferrule Fittings Ti-6al-4v Eli Titanium Ferrule Fittings Pure Titanium Pneumatic Fittings Ti Grade 6 Flare Fittings Cp Gr2 Ti JIC Fittings Tial6v4 Instrumentation Fittings Ti Alloy Grade 5 Hydraulic Hose Fittings ASTM B348 Grade 5 Compression Fittings Cp Grade 1 Double Ferrule Fittings ASME SB 348 Grade 2 Push-To-Connect Fittings Grade 5 Compression Fittings Ti Gr2 Hydraulic Fittings |
| Material Grades | Titanium Gr.5 – UNS R56400, Titanium Gr 2 – UNS R50400 |
| THREAD | BSPT, UNF, BSP, NPT, ISO, SAE, etc. |
| Forms | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Working Pressure | Upto 2000 to 6000 PSI |
| Medium – Pressure Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) |
| Body Type | FORGED, BAR STOCK |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Surface | Export bright finish, short blasted finish, electroplated finish |
| Applications Temperature | 150-400°C |
| Ends | Welding, Threaded, JIC |
| Packing Details | As per your detailed request Normally carton size – 21*16*14CM/31*21*16CM/36*45*50CM Normally wooden box size – 38*27*17CM Normally 1piece/ opp, 10-20pcs/ carton |
| Element | Ti | C | Fe | H | N | O | Al | V |
| Titanium | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Tube Fittings in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium tube fittings are widely used in applications where high corrosion resistance, strength and lightweight are required. In the aerospace industry they are used in water systems, fuel lines, and equipment hoses due to their resistance to extreme temperatures and environmental corrosion In the marine industry they are ideal for seawater applications, such as piping and heat exchangers. The pharmaceutical industry uses these materials to manage biodegradable products, while the pharmaceutical industry relies on them to create biocompatible vessels in implantable devices and surgery.
