Xuan Nickel Alloys, which has its base of operations in Da Nang, Vietnam, is a reliable producer and supplier of high-quality Titanium Grade 2 Tube Fittings. With years of experience and a strong focus on research and development, the company supplies products of international quality and varied industrial requirements. Xuan Nickel Alloys’ Titanium Grade 2 Tube Fittings are well known for their great corrosion resistance, light-weight construction, and strength and are crucial in sensitive industries. Made with utmost precision and through the use of advanced methods, these fittings provide exceptional reliability and extended life of service, positioning Xuan Nickel Alloys as a worldwide partner for high-performance solutions.
Titanium Grade 2 Tube Fittings consist of 99.2% titanium and trace amounts of iron, oxygen, and carbon. They offer a balance of toughness, corrosion resistance, and strength. They have a tensile strength of approximately 345 MPa and a yield strength of around 275 MPa with satisfactory ductility and weldability. Such characteristics help the fittings function well in challenging environments. Their superior strength-to-weight ratio and good corrosion resistance, especially in oxidizing environments, render them extremely versatile and reliable for industrial and biomedical applications.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Grade 2 Tube Fittings in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Grade 2 Tube Fittings are widely used where high strength and corrosion resistance at low weight are required. Aerospace uses them for hydraulic components, fuel lines, and structural components because they can withstand harsh environments. The marine sector gains from their resistance in seawater exposed piping systems. Chemical and pharmaceutical industries use these fittings to handle corrosive liquids while providing hygienic conditions. Their biocompatibility further makes them ideal for medical devices and surgical use. In general, their versatility across harsh environments guarantees enduring performance, thus making them an essential option for various high-tech sectors.
