Xuan Nickel Alloys is a leading manufacturer and supplier of Super Duplex Steel Stud Bolts in Da Nang, Vietnam. Our Super Duplex Steel Stud Bolts are designed to deliver exceptional strength, durability, and resistance to corrosion, making them perfect for the most demanding applications. With superior mechanical properties and excellent performance in harsh environments, these stud bolts are ideal for industries such as oil and gas, marine, and chemical processing. At Xuan Nickel Alloys, we are committed to upholding the highest industry standards through advanced manufacturing techniques and rigorous quality control. Our dedication to excellence ensures that every Super Duplex Steel Stud Bolt meets the toughest requirements, making us the trusted choice for clients across Da Nang and beyond.
Xuan Nickel Alloys stands out as a top manufacturer and supplier based in Da Nang, Vietnam, specializing in high-quality Super Duplex Steel Stud Bolts designed for tough industrial fastening needs. These bolts are celebrated for their exceptional strength, toughness, and impressive resistance to corrosion. Crafted with a unique dual-phase microstructure of austenite and ferrite, they offer remarkable protection against pitting, crevice corrosion, and stress corrosion cracking, making them perfect for challenging environments rich in chlorides. At Xuan Nickel Alloys, we pride ourselves on delivering precision-engineered Super Duplex Steel Stud Bolts that adhere to international safety and performance standards.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
These Super Duplex Steel Stud Bolts are made from a blend of high chromium (around 25%), nickel, molybdenum, and nitrogen, which together provide outstanding corrosion resistance and enhanced mechanical properties. They boast impressive tensile strength ranging from 800 to 1000 MPa, with yield strength nearly twice that of standard austenitic stainless steels. Even in sub-zero temperatures, these bolts maintain excellent impact toughness and ductility. Their well-balanced composition ensures superior resistance to chloride-induced stress corrosion cracking and localized corrosion, making them ideal for high-pressure and aggressive operating conditions.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Stud Bolts find their place in various industries where strong and dependable fastening is crucial under extreme conditions. They are commonly used in offshore platforms, subsea pipelines, and marine structures that face saline environments. In the oil and gas sector, you’ll find them in pressure vessels, heat exchangers, reactors, and process piping. Chemical and petrochemical plants depend on them for managing corrosive substances, while industries like power generation, desalination, and pulp and paper rely on their durability. Additionally, these stud bolts are essential in heavy structural assemblies and critical engineering projects that demand long service life and maximum reliability.
