Xuan Nickel Alloys is a leading manufacturer and supplier of Super Duplex Steel Stud Bolts S32760 in Da Nang, Vietnam. Our S32760 stud bolts are engineered to deliver superior performance in the most challenging environments, offering exceptional strength, corrosion resistance, and durability. Ideal for use in the oil and gas industry, chemical processing, and marine applications, these stud bolts are designed to withstand extreme conditions, including exposure to seawater and aggressive chemicals. With a strong commitment to quality and precision, Xuan Nickel Alloys ensures that each product meets international standards, providing our clients with reliable fastening solutions for critical operations. Trust us for high-quality Super Duplex Steel Stud Bolts that deliver long-lasting results.
Xuan Nickel Alloys is a reputable manufacturer and supplier based in Da Nang, Vietnam, specializing in high-performance Super Duplex Steel Stud Bolts S32760. These stud bolts are celebrated for their remarkable strength, toughness, and outstanding resistance to corrosion, making them perfect for critical fastening tasks in harsh environments. With a well-balanced dual-phase microstructure of austenite and ferrite, S32760 stud bolts offer excellent protection against pitting, crevice corrosion, and stress corrosion cracking. At Xuan Nickel Alloys, we pride ourselves on delivering precision-engineered fastening solutions that meet international standards across offshore, chemical, marine, and energy sectors.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32760 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
Super Duplex Steel Stud Bolts S32760 are made up of about 25% chromium, 7% nickel, and 3.5% molybdenum, along with tungsten and nitrogen to boost corrosion resistance. They showcase impressive mechanical properties, with tensile strength ranging from 800 to 1000 MPa and yield strength that is nearly double that of standard stainless steels. These bolts retain excellent toughness and impact resistance, even in low-temperature conditions. The advanced composition of the alloy ensures strong resistance to chloride-induced stress corrosion cracking and localized corrosion, making them ideal for fastening in highly corrosive and high-pressure settings.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Stud Bolts S32760 find extensive use in industries that demand reliable fastening under extreme conditions. They’re commonly utilized in offshore platforms, subsea pipelines, and marine structures where durability is crucial due to exposure to saline environments. In the chemical and petrochemical sectors, they are essential for pressure vessels, heat exchangers, reactors, and process piping. Power generation facilities, desalination plants, and the pulp and paper industries also depend on these stud bolts for their long service life and safety. Additionally, they are employed in heavy structural applications and critical assemblies where superior strength and corrosion resistance are vital.
