Xuan Nickel Alloys is a leading manufacturer and supplier of Super Duplex ball valves in Da Nang, Vietnam. Our super duplex ball valves are designed to deliver excellent strength, superior durability and superior corrosion resistance, making them ideal for the most demanding industrial applications These valves excel in high pressure systems, aggressive chemicals and extreme temperatures so for reliable operation and long-term stability There is no doubt that it is widely used in chemical manufacturing, offshore oil and gas industry and power industry. We adhere to strict quality standards to ensure each valve meets stringent industry requirements. Choose Xuan Nickel Alloys for premium super duplex ball valves that deliver exceptional quality and accuracy for your specific needs.
Xuan Nickel Alloys stands out as a top manufacturer and supplier based in Da Nang, Vietnam, specializing in high-quality Super Duplex Ball Valves tailored for demanding industrial applications. These valves are crafted for durability and reliability, boasting exceptional corrosion resistance, making them perfect for aggressive and high-pressure environments. With a unique dual-phase microstructure of austenite and ferrite, Super Duplex Ball Valves excel in resisting pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. At Xuan Nickel Alloys, we pride ourselves on delivering precision-engineered ball valves that adhere to international standards, catering to industries like oil and gas, chemical, petrochemical, marine, desalination, and power generation.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
Our Super Duplex Ball Valves are constructed from high-performance alloys that include about 25% chromium, nickel, molybdenum, and nitrogen, all of which enhance their mechanical strength and corrosion resistance. They offer impressive tensile strength ranging from 800 to 1000 MPa, with yield strength nearly double that of standard austenitic stainless steels. Even in sub-zero temperatures, these valves maintain excellent toughness and ductility. Their advanced alloy composition ensures they resist chloride-induced stress corrosion cracking, localized corrosion, and erosion, making them a reliable choice for managing aggressive fluids in high-pressure systems.
Contact us to get a quick quote for your requirement.
These Super Duplex Ball Valves are widely utilized in industries where dependable flow control and corrosion resistance are crucial. They’re extensively used in offshore platforms, subsea systems, and marine applications that face saline environments. In the oil and gas sector, they play a vital role in pipelines, process systems, and high-pressure fluid handling. Chemical and petrochemical plants depend on them for handling aggressive media, while desalination and power generation facilities appreciate their long service life. Moreover, these valves are perfect for critical process systems that require precise, safe, and durable flow control.
