Home > Duplex Steel > Duplex Steel Wire
Xuan Alloys, a top-notch manufacturer and supplier based in Da Nang, Vietnam, specializes in high-quality Duplex Steel Wire designed for exceptional strength, corrosion resistance, and durability in tough industrial settings. Crafted to meet international standards, these wires come in a variety of diameters, coil lengths, and finishes to cater to a wide range of applications. Duplex Steel Wire is perfect for industries like chemical processing, petrochemical, marine, and power generation, ensuring reliable performance and a long lifespan even in harsh and corrosive environments.
This wire is primarily made from a balanced blend of austenitic and ferritic stainless steel, featuring essential elements such as Chromium, Nickel, Molybdenum, and Nitrogen. This unique composition grants it outstanding resistance to pitting, crevice, and stress corrosion cracking, along with impressive mechanical properties. In terms of mechanics, Duplex Steel Wire boasts high tensile strength, toughness, and fatigue resistance, making it ideal for high-pressure, high-temperature, and corrosive conditions.
| Duplex Wire Standard | ASTM A276, A479 / ASME SA276, SA479 AMS 5514 |
|---|---|
| Duplex Steel / Wire Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Duplex Wire Length | Cut Lengths: 0.125″ to 72″ No Limit on Spooled Lengths |
| Duplex Wire Diameter | 0.0004″ to 0.040″ 10 microns to 1.0 mm Other Sizes on Request |
| Wire Density | 8.89 g/cm3 |
|
580-750 |
|
as standard |
|
28-30 |
| Surface | Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated |
| Tempers | Tempers range from dead soft annealed to ultra spring temper |
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| S31803 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 21.0 – 23.0 | 4.5- 6.5 | 2.5 – 3.5 | 0.08 – 0.20 |
| S32205 | 0.03 max | 2.0 max | 1.0 max | 0.03 max | 0.010 max | 22.0 – 23.0 | 4.5- 6.5 | 3.0 – 3.5 | 0.14 – 0.20 |
| Tensile Strength | 650 -850MPa |
| Elongation (Min) | 30 % |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel Wire in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find Duplex Steel Wire commonly used in chemical processing equipment, heat exchangers, pressure vessels, piping systems, and marine applications that face aggressive chemicals and seawater. Its blend of mechanical reliability, corrosion resistance, and long-lasting durability makes Duplex Steel Wire a trustworthy choice for critical industrial and engineering tasks that demand strength and performance in challenging environments.
