Xuan Nickel Alloys produces and distributes high-grade Inconel needle valves in Da Nang, Vietnam, designed to deliver superior durability and precision control. Constructed to resist aggressive chemicals, extreme temperatures, and severe industrial environments, these valves are well suited for application in chemical processing, aerospace, marine, and oil and gas sectors. Every valve is subjected to stringent quality control to guarantee superior corrosion resistance, reliability, and long-term performance. Xuan Nickel Alloys strives to provide high-quality Inconel needle valves that blend precision, strength, and durability to give customers reliable solutions that ensure operational integrity in the harshest environments and most critical applications.
Inconel needle valves are constructed from high-performance nickel-chromium-based superalloys, like Inconel 600, 625, or 718. The alloys possess excellent corrosion resistance in harsh environments and against harsh chemicals. The mechanical properties are high tensile strength, superior creep resistance, and high-temperature stability. The valves are resistant to oxidation, stress corrosion cracking, and wear, providing long-term durability and trouble-free performance at high pressures and thermal cycling. Their accurate design enables precise flow control, integrating strength mechanical performance and chemical resistance, making them ideal for industrial use where strength, dependability, and resilience against extreme conditions are a necessity.
| MATERIAL | INCONEL |
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| ORIFICE SIZE | 2 MM – 9.5 MM |
| FLOW PATTERN | ANGLE, STRAIGHT, CROSS PATTERNS |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGE END |
| BODY SHAPE | ROUND, SQUARE, HEXAGON |
| PRESSURE RATING | 15,000 PSI, 3000 PSI, 1500 PSI, 10000 PSI, 6000 PSI, 20000 PSI |
| FUNCTION | 3 WAY, 2 WAY |
| BODY TYPE | FORGED, BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C – 500*C ) AS PER PRESSURE RANGE |
| HANDLE | KNOB HANDLE, BAR T-HANDLE, WHEEL HANDLE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Cr | C | Mn | Si | S | Ni | Cu | Fe |
| Inconel 625 | 20.0 – 23.0 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | 58.0 min | 1.00 max | 5.0 max |
| Elongation in 2 “ (%) | .2% Yield (psi) | Temp° F | Tensile (psi) |
|---|---|---|---|
| 45 | 61,000 | 800 | 131,500 |
| 59 | 58,500 | 1400 | 78,000 |
| 45 | 66,000 | 400 | 134,000 |
| 44 | 84,000 | 70 | 144,000 |
| 48 | 60,500 | 1000 | 130,000 |
| 42.5 | 63,000 | 600 | 132,000 |
| 34 | 60,000 | 1200 | 119,000 |
| 117 | 39,000 | 1600 | 40,000 |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Needle Valve in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel needle valves are globally used in processes that demand accurate flow management under harsh conditions. They control aggressive fluids and high pressure levels, maintaining safe and effective operations, in chemical processing. Aerospace makes use of the valves for fuel, hydraulic, and cooling systems because of their corrosion tolerance and resistance to temperature variations. Marine environments appreciate their robustness in seawater and hostile environments, while the oil and gas industry depends on them for high-pressure processing and pipeline systems. Moreover, the valves find application in power plants and petrochemical facilities, offering precise control, long-term reliability, and low maintenance in demanding industrial and high-temperature applications.
