At Xuan Nickel Alloys, we pride ourselves on being a premier manufacturer and supplier of Inconel forged fittings in Da Nang, Vietnam. With a commitment to exceptional quality and precision, we specialize in providing durable and high-performance forged fittings designed to meet the rigorous demands of various industries. Our products, including Inconel forged fittings, are crafted to offer superior resistance to extreme temperatures and corrosive environments, ensuring reliability and longevity in every application.
Xuan Nickel Alloys is a reputable manufacturer and supplier based in Da Nang, Vietnam, specializing in high-quality Inconel Forged Fittings that are perfect for demanding and corrosive environments. Crafted from Inconel, a robust nickel-chromium alloy, these fittings are designed to withstand high-temperature oxidation, chemical corrosion, and stress corrosion cracking with ease. Thanks to their impressive mechanical strength, toughness, and durability, Inconel Forged Fittings guarantee secure, leak-proof connections across various industries, including chemical, petrochemical, oil and gas, marine, aerospace, and power generation.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
These fittings boast remarkable mechanical properties, such as high tensile and yield strength, impact resistance, and stability across a broad temperature spectrum—from cryogenic conditions to elevated service temperatures. They effectively resist pitting, crevice corrosion, and oxidation, ensuring reliable performance even in high-pressure, high-temperature, and aggressive chemical settings. The forging process not only enhances their dimensional accuracy but also strengthens their structural integrity, making them a top choice for critical piping systems.
Contact us to get a quick quote for your requirement.
Inconel Forged Fittings find their applications in offshore platforms, chemical and petrochemical plants, refineries, heat exchangers, pumps, and valves. In the oil and gas sector, they are essential for high-pressure pipelines, subsea systems, and sour gas service. Additionally, industries like aerospace, defense, and power generation depend on Inconel Forged Fittings for vital mechanical connections where corrosion resistance, strength, and reliability are non-negotiable.
