Xuan Nickel Alloys, Da Nang, Vietnam, is a trusted Inconel 601 stud bolt manufacturer and supplier to thermal processing, petrochemical, power generation, and aerospace industries. These high-performance stud bolts are intended for applications in corrosive and high-temperature environments where regular materials are not effective. Xuan Nickel Alloys manufactures Inconel 601 stud bolts in different sizes and thread forms, with strict quality control and accurate machining to provide durability, strength, and reliable performance in high-reliability bolted assemblies.
Inconel 601 is an alloy of nickel-chromium-iron with additions of aluminum that provides excellent resistance to high-temperature corrosion and oxidation. Its standard composition consists of 58–63% nickel, 21–25% chromium, and a maximum of 1.7% aluminum. Inconel 601 stud bolts provide tensile strength of approximately 600 MPa and yield strength of about 275 MPa, with superb thermal stability up to 1200°C. The alloy resists scaling, carburization, sulfidation, and spalling under cyclic heating, making the alloy perfect for applications that need both mechanical integrity and corrosion resistance during extended service periods.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 stud bolts are utilized heavily in furnace design, exhaust equipment, heat-treating units, and chemical processing facilities. They are best suited to fasten parts in high-temperature flanged connections and pressure vessels where creep and oxidation resistance are required. The fasteners can be utilized in power plants and refineries where machinery is subjected to thermal cycling and hostile gases. Their long-term integrity, even at extreme thermal and chemical conditions, renders Inconel 601 stud bolts the first choice for engineers in designing critical systems under extreme industrial conditions.
