Xuan Nickel Alloys, located in Da Nang, Vietnam, is a reputable manufacturer and supplier of Inconel 600 stud bolts, offering high-quality fastening solutions for demanding industrial environments. These stud bolts are generally applied in heat treatment, chemical processing, nuclear, and marine applications where superior resistance to high temperature and corrosive media is needed. Xuan Nickel Alloys manufactures Inconel 600 stud bolts with accurate threading, superior surface quality, and consistent mechanical strength, providing long-lasting performance in critical bolted and flanged assemblies.
Inconel 600 is a nickel-chromium-iron alloy strengthened by a solid solution that has superior resistance to oxidation and corrosion. Its standard form consists of 72% nickel, 14–17% chromium, and 6–10% iron. Inconel 600 stud bolts provide tensile strength approximately 655 MPa with yield strength of about 310 MPa, showing good resistance against chloride-ion stress corrosion cracking. The stud bolts prove to be structurally strong at temperatures of cryogenic level up to 1093°C. The stability of the alloy and its non-magnetic property qualify it for both corrosive and high-heat conditions of service.
| Specifications | ASTM A166 / ASME A166 |
| Standard | DIN, ISO ,JIS ,GB, IS, BS, ASTM and all International Standards |
| Size | M3 – M100 | 3/6″ – 4″ | Custom Sizes |
| Length | 3 mm – 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Head | Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc. |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc. |
| Surface Treatment | Passivation /plain |
| Others Factor | OEM, ODM, ±0.03MM tolerance |
| Manufacturing Process | Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing. |
| Packing | IN BULK: carton, pallet, Small Boxes or customer request |
| Surface Coating | Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Stud Bolts in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 stud bolts find broad utilization in heat exchangers, nuclear steam generators, furnace components, chemical reactors, and marine systems. They ensure safe and long-lasting fastening in high-heat, high-pressure, and aggressive chemical environments. The stud bolts are particularly beneficial in systems with thermal cycling, oxidation, and high moisture content. Their resistance to scaling, durability, and high mechanical strength are reasons why Inconel 600 stud bolts are a first choice for long-term application in extreme industrial conditions.
