Home > Invar 36 Sheet and Plates
Xuan Nickel Alloys is a reputable manufacturer and supplier of top-notch Invar 36 Sheets and Plates, proudly based in Da Nang, Vietnam. Renowned for their precision in manufacturing, rigorous quality control, and commitment to international standards, the company delivers products that boast exceptional dimensional stability and minimal thermal expansion. Their Invar 36 Sheets and Plates are perfect for applications where even the slightest dimensional changes due to temperature shifts are crucial. Catering to industries like aerospace, cryogenics, marine, and instrumentation, Xuan Nickel Alloys guarantees prompt delivery, competitive pricing, and customized solutions. With a strong focus on innovation and reliability, they have become a go-to partner for specialty alloy products around the globe.
Invar 36 Sheets and Plates are iron-nickel alloys with about 36% nickel, designed for ultra-low thermal expansion. They provide outstanding dimensional stability, impressive toughness, and good ductility, even in cryogenic conditions. Their mechanical properties include a coefficient of thermal expansion close to 1.2 × 10⁻⁶/°C between –100 °C and +200 °C, tensile strengths ranging from 450 to 650 MPa, and excellent machinability. These sheets and plates maintain their stability during temperature changes and offer good corrosion resistance in typical environments, making them ideal for high-precision, low-expansion applications across various industrial sectors.
| Standards : | ASTM F1684 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc |
| Grade | C | Mn | Si | S | Co | Fe | Mo | Al |
| Invar 36 | .008 max | .30 max | .15 max | .001 max | .35 max | 63.0 max | .02 max | .03 max |
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Invar 36 | KSI (MPa) 63 / (430) Max | KSI (MPa)-38 / (260) Max | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Invar 36 | 1.3912 | K93600 | K93603 |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Invar 36 Sheets and Plates are essential in industries that require precise dimensional stability across a range of temperatures. The aerospace and aviation sectors utilize them for tooling, jigs, and precision molds. In cryogenic applications, you’ll find them in storage tanks, pipelines, and scientific equipment that operate in extremely low temperatures. They’re also crucial in marine and defense industries for sensitive structural components that face thermal fluctuations. Additionally, Invar 36 is used in optical instruments, electronic devices, and high-precision measuring tools. With their low thermal expansion, excellent machinability, and reliability, Invar 36 Sheets and Plates are vital for critical engineering, manufacturing, and instrumentation needs around the globe.
