Xuan Alloys, a well-respected manufacturer and supplier based in Da Nang, Vietnam, proudly offers top-notch Duplex Steel 2205 Coils. These coils are known for their impressive strength and outstanding resistance to corrosion. Crafted in line with international quality standards, they come in various sizes, finishes, and specifications to cater to a wide range of industrial requirements. Thanks to their remarkable durability and long service life, Duplex Steel 2205 Coils are the go-to choice for industries that demand reliability and performance in tough conditions, such as marine, oil & gas, and chemical processing.
Standard ASTM A240 / ASME SA240
Range 5mm To 150mm
Width 1000mm / 1219mm /1250mm / 1500mm / 2000mm
Length 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm.
Surface Finishing Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 2205 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Steel 2205 Coils in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel 2205 Coils find extensive applications across various industries, including petrochemicals, oil & gas, desalination, pulp & paper, power generation, and marine engineering. They are perfect for creating heat exchangers, storage tanks, pressure vessels, pipelines, and marine components that require both high strength and corrosion resistance. With their blend of durability, cost-effectiveness, and ability to withstand aggressive environments, Duplex Steel 2205 Coils stand out as a dependable choice for critical engineering and industrial applications.
