Xuan Nickel Alloys is a leading manufacturer and supplier of high quality steel in Da Nang, Vietnam. We specialize in a wide range of materials, offering unique materials such as Alloy C263 foil, which is known for its high temperature and excellent corrosion resistance. Our alloy C263 foil is widely used in industries such as aerospace, chemical processing and power generation. With a commitment to quality and customer satisfaction, we offer reliable, robust and cost-effective solutions to meet your specific compounding needs.
Xuan Nickel Alloys is a trusted manufacturer and supplier of premium Alloy C263 Foil in Da Nang, Vietnam. Acclaimed for accurate engineering and strict compliance with international standards, Xuan supplies nickel-based alloy products to high-performance industries globally. Equipped with state-of-the-art facilities and experienced experts, the company ensures efficient production, consistent quality, and punctual delivery. Alloy C263 Foil is one of Xuan’s premium products, designed to address applications in industries like aerospace, power generation, and chemical processing. With a focus on innovation and customer satisfaction, Xuan Nickel Alloys becomes a preferred supplier both regionally and internationally.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
Alloy C263 Foil is a nickel-cobalt-chromium-molybdenum superalloy designed with higher high-temperature strength and corrosion resistance. Its normal composition is around 20% chromium, 20% cobalt, 5.9% molybdenum, and nickel balance, with small additions of such elements as titanium and aluminum for precipitation hardening. It has high tensile strength, excellent ductility, and excellent creep resistance above 800°C. Its mechanical properties are thermally cycle stable and suited best to uses where long life and structural integrity are needed. These traits make Alloy C263 Foil a suitable substance for precision-engineered, heat-tolerant components.
Contact us to get a quick quote for your requirement.
Alloy C263 Foil finds extensive use in applications where high strength, thermal stability, and corrosion resistance are essential. In the aerospace sector, it is used in combustion cans, turbine parts, and exhaust systems, where it is subjected to intense heat and stress. In power generation and gas turbines, the foil is applied in the high-temperature parts that require extended life. Its corrosion resistance also makes it suitable for chemical processing equipment under harsh media. The foil is also recommended for applications that involve thin-gauge metal components that require accuracy due to its surface finish as well as formability.
