Xuan Nickel Alloys is a leading manufacturer of high quality nickel alloy and A286 foil in Da Nang, Vietnam. With a reputation for excellence, we handle a range of industries including aviation, automotive and industrial. Our A286 foils are known for exceptional durability, durability and resistance to extreme conditions while meeting international quality standards. At Xuan Nickel Alloys, we put innovation, accuracy and customer satisfaction first, offering customized solutions to meet your specific needs. Partner with us for reliable and efficient services.
Xuan Nickel Alloys is among Da Nang, Vietnam’s A286 Foil manufacturers and suppliers. Xuan has a long background of experience in processing nickel and high-performance alloys and offers high-quality A286 Foil for demanding applications in aerospace, automotive, power generation, and chemical processing industries. The company uses modern manufacturing methods, quality inspection, and international standards to provide consistent product performance. Dedicated to timely supply and quality customer services, Xuan Nickel Alloys provides domestic and overseas markets tailored solutions for key components with strength, heat resistance, and corrosion resistance in harsh operating conditions.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
A286 Foil is an iron-nickel-chromium-based superalloy that is widely acknowledged to have fine high-temperature strength, good corrosion resistance, and excellent fabricating features. It is normally composed of approximately 15% chromium, 25% nickel, and trace amounts of vanadium, molybdenum, and titanium for hardening by precipitation. The alloy possesses high tensile strength and creep resistance up to 700°C with excellent oxidation and fatigue resistance. The mechanical properties are excellent yield strength, high elongation, and excellent toughness. A286 Foil retains its shape at both high and low temperatures and is therefore a good option for thermally stressed critical parts.
Contact us to get a quick quote for your requirement.
A286 Foil finds broad usage in applications involving high strength and stability under high temperatures. It is extensively applied in the aerospace industry in turbine engines, afterburner parts, and fasteners due to its excellent heat resistance and strength-to-weight ratio. The automotive sector applies A286 Foil in exhaust and turbocharger parts where heat resistance and corrosion resistance are of equal importance. In power generation and chemical processing, springs, diaphragms, and other thin-gauge products used in hostile environments and at high temperatures are applied. Its general versatility, strength, and formability make it a requirement in precision-engineered thermal components.
