Home > Tantalum Shim
Xuan Alloys, a top-notch manufacturer and supplier based in Da Nang, Vietnam, specializes in high-quality Tantalum Shims that are built to withstand corrosion, high temperatures, and wear and tear. These shims are crafted according to strict international standards and come in a variety of thicknesses, sizes, and finishes to cater to a wide range of industrial needs. Tantalum Shims are perfect for use in chemical processing, aerospace, electronics, and medical fields, ensuring reliable performance even in harsh environments filled with aggressive chemicals, extreme heat, and high-stress situations.
Made primarily from tantalum—a rare metal known for its impressive corrosion resistance—these shims may also include trace impurities that enhance their mechanical properties. This unique composition provides exceptional resistance to strong acids like hydrochloric, sulfuric, and nitric acids, along with protection against pitting and crevice corrosion. On the mechanical side, Tantalum Shims boast good ductility, a high melting point, and excellent toughness, making them ideal for precision applications where both strength and corrosion resistance are essential.
| Standards : | ASTM / ASME |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Element | R05200 (%,Max) | R05400 (%,Max) |
| C | 0.01 | 0.01 |
| O | 0.015 | 0.03 |
| N | 0.01 | 0.01 |
| H | 0.0015 | 0.0015 |
| Fe | 0.01 | 0.01 |
| Mo | 0.02 | 0.02 |
| Nb | 0.1 | 0.1 |
| Ni | 0.01 | 0.01 |
| Si | 0.005 | 0.005 |
| Ti | 0.01 | 0.01 |
| W | 0.05 | 0.05 |
| Grade | Tensile strength δbpsi (MPa)， ≥ | Yield strength δ0.2， psi (MPa)，≥ | Elongation in 1″/2″ gage length， ％， ≥ |
| RO5200/RO5400 | 30000 (207) | 20000 (138) | 25 |
| RO5252 | 40000 (276) | 28000 (193) | 20 |
| RO5255 | 70000 (481) | 60000 (414) | 15 |
| RO5240 | 40000 (276) | 28000 (193) | 20 |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find Tantalum Shims commonly used in chemical processing equipment, heat exchangers, and reactor components that come into contact with aggressive acids. In the aerospace and electronics sectors, they serve important roles in thermal and electrical shielding. Medical devices also take advantage of their biocompatibility and chemical stability. With their impressive combination of corrosion resistance, durability, and high-temperature performance, Tantalum Shims stand out as a dependable and long-lasting choice for critical applications in industry, engineering, and medicine.
