Xuan Nickel Alloys is a leading manufacturer and supplier based in Da Nang, Vietnam, specializing in high-quality nickel alloys. Renowned for our precision and reliability, we offer a comprehensive range of Monel 400 sheets and plates designed to meet the rigorous demands of various industries. Monel 400 is known for its exceptional resistance to corrosion and high strength, making it ideal for challenging environments. We ensure top-notch products and services to meet diverse industrial needs.
Xuan Nickel Alloys is a well-respected manufacturer and supplier based in Da Nang, Vietnam, specializing in top-notch Monel 400 Sheets and Plates that excel in tough and corrosive environments. Crafted from a robust nickel-copper alloy, Monel 400 is celebrated for its remarkable resistance to seawater, acids, alkalis, and steam. These sheets and plates not only offer exceptional corrosion resistance but also boast high strength and toughness, making them a dependable choice for industries like marine, chemical, oil and gas, and power generation. With a variety of thicknesses, sizes, and finishes available, Monel 400 Sheets and Plates adhere to international standards for durability and precision.
| Specifications | ASTM / ASME SB 127 |
|---|---|
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
The mechanical properties of Monel 400 Sheets and Plates are outstanding, featuring high tensile and yield strength, along with good ductility and toughness across a broad temperature range—from cryogenic conditions to elevated service temperatures. They effectively resist pitting, crevice corrosion, chloride-induced stress corrosion cracking, and oxidation, ensuring they perform reliably in harsh conditions. Their excellent thermal conductivity and ability to endure both oxidizing and reducing environments make them versatile for critical industrial applications.
Contact us to get a quick quote for your requirement.
When it comes to uses and applications, Monel 400 Sheets and Plates are essential in shipbuilding, seawater handling equipment, desalination plants, offshore platforms, and marine hardware. In the chemical and petrochemical sectors, they are commonly found in heat exchangers, evaporators, pumps, storage tanks, and processing equipment that come into contact with aggressive fluids. The oil and gas industry also relies on them for refinery equipment, sour gas services, and subsea structures. Additionally, the power generation and aerospace sectors trust Monel 400 Sheets and Plates for their strength, reliability, and corrosion resistance in high-performance systems.
