Xuan Nickel Alloys, a well-established manufacturer and exporter based in Da Nang, Vietnam, supplies Jethete M152 sheets and plates. Reputed for its emphasis on high-performing alloys, Xuan Nickel Alloys offers precision-manufactured Jethete M152 products for challenging aerospace, power generation, and defense requirements. With sophisticated manufacturing capabilities and rigorous quality control, the company guarantees top-quality consistency and mechanical reliability in each sheet and plate. Their Jethete M152 products are manufactured to international standards and customer specifications and are, therefore, a reliable source for industries requiring high strength, corrosion resistance, and superior creep performance at high temperatures.
| Standard Specification : | ASTM A666 / ASME SA666, Jethete M152 (BS S151/ S159) | MSRR 6503 | AMS 5719 | DTD 5066 | WS 1.4933 | AECMA FE-PM37 | UNS S64152 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| C | Si | Mn | P+S max | Cr | Mo | Ni | N | V |
| 0.08-0.13 | 0.35 max | 0.50-0.90 | P 0.030 S 0.025 | 11-12.5 | 1.50-2.0 | 2-3 | 0.02-0.04 | 0.25-0.40 |
| Grade | Treatment | Tensile Strength Mpa | Yield Strength Mpa | Elongation % | Hardness HB | Ruling Section |
| S151A S151D | Softened Finally Heat Treated | 930-1130 | 780 | 14 | 311max 286-311 | – 150mm |
| S159A S159D | Softened Finally Heat Treated | 1100-1300 | 900 | 8 | 311 max 321-388 | 50mm |
| AMS 5719 AMS 5719 | Annealed Hardened & Double Templerd | 1069 min | 896 | 12 | 311 341-375 | – – |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Jethete M152 sheets and plates are applied extensively in critical aerospace components like turbine blades, discs, shafts, and fasteners where high strength along with creep resistance is a must. In power generation, they are used in steam turbine components and high-pressure equipment subjected to intense heat and mechanical loads. Their long life makes them most suitable for use in military and defense, such as high-performance engine components and structural elements. Jethete M152’s machinability, heat resistance, and mechanical stability make it a highly sought-after material in industries where high-performance under harsh operating conditions is needed.
