Home > Haynes 230 Sheets and plates
Xuan Nickel Alloys stands out as a reliable manufacturer and supplier based in Da Nang, Vietnam, specializing in top-notch Haynes 230 Sheets and Plates tailored for high-performance industrial needs. These sheets and plates are crafted to deliver outstanding corrosion resistance, impressive strength at high temperatures, and long-lasting durability, making them perfect for challenging chemical and high-heat environments. With a focus on advanced precision and rigorous quality control, the Haynes 230 Sheets and Plates from Xuan Nickel Alloys adhere to international standards, guaranteeing consistent performance and dependability. They find extensive application in the chemical processing, petrochemical, power generation, and aerospace sectors, where they serve as critical components in extreme conditions.
| Specification : | AMS 5878 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 230 (UNS N06230) |
| Weight% | C | Mn | Si | P | S | Cr | Co | Fe | Al | Ti | B | Cu | La | W | Mo | Ni |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.25-0.75 | 0.03 | 0.015 | 20.0-24.0 | 5.0 | 3.0 | 0.20-0.50 | 0.10 | 0.015 | 0.50 | 0.005-0.05 | 13.0-15.0 | 1.0-3.0 | Rem |
| Material | Test Temp °F | Ultimate Tensile Strength | 0.2 % Yield Strength | Elongation in % | Hardness HB |
| Haynes Alloy 230 Extruded Bar Solution Treated (AMS 5891) | RT | 758 Mpa 110 ksi | 310 Mpa 45 ksi | 35 | 241 max |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Industries that demand corrosion-resistant and heat-resistant materials widely utilize Haynes 230 Sheets and Plates. In chemical processing and petrochemical facilities, they are used for reactors, heat exchangers, piping systems, and vessels that come into contact with strong acids and oxidizing agents. The power generation sector employs them in boilers, superheaters, and turbine components. Additionally, the aerospace and marine industries rely on Haynes 230 Sheets and Plates for high-temperature structural components and essential systems. Their durability, resistance to corrosion, and performance at high temperatures make them essential in these demanding applications.
