Xuan Nickel Alloys, a leading manufacturer and supplier based in Da Nang, Vietnam, specializes in providing high-quality Monel Forged Fittings. Renowned for their durability and resistance to corrosion, these fittings are essential in industries requiring robust performance under extreme conditions. Our Monel Forged Fittings are meticulously crafted to meet international standards, ensuring reliability and longevity. Trusted by clients across various sectors, Xuan Nickel Alloys is your go-to source for premium Monel Forged Fittings in the Vietnam and beyond.
Xuan Nickel Alloys stands out as a reliable manufacturer and supplier based in Da Nang, Vietnam, specializing in high-quality Monel Forged Fittings that are perfect for tough applications in corrosive and high-pressure settings. Crafted from top-notch Monel alloys, these fittings boast impressive resistance to seawater, acids, alkalis, and stress corrosion cracking caused by chlorides. With their exceptional mechanical strength, toughness, and long-lasting durability, Monel Forged Fittings guarantee secure, leak-proof connections across various industries, including marine, chemical, petrochemical, oil and gas, aerospace, and power generation.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
These fittings are known for their remarkable mechanical properties, featuring high tensile and yield strength, toughness, and stability across a broad temperature range—from freezing conditions to high heat. They effectively resist pitting, crevice corrosion, stress corrosion cracking, and oxidation, ensuring reliable performance even in harsh chemical and seawater environments. The precision forging process enhances their dimensional accuracy and structural integrity, making them ideal for high-pressure and critical piping systems.
Contact us to get a quick quote for your requirement.
Monel Forged Fittings find their applications in shipbuilding, offshore platforms, seawater desalination plants, chemical and petrochemical process piping, heat exchangers, pumps, and valves. In the oil and gas sector, they are commonly used in high-pressure pipelines, subsea systems, and sour gas services. Additionally, industries like aerospace, defense, and power generation depend on Monel Forged Fittings for essential mechanical connections that require both corrosion resistance and long-term structural reliability.
