Xuan Nickel Alloys is a reputable manufacturer and supplier of Copper Nickel 90/10 Bars based in Da Nang, Vietnam. They pride themselves on delivering top-notch products that cater to the needs of industries around the globe. With a strong focus on precision engineering and a commitment to international standards, the company offers bars that are known for their outstanding durability, resistance to corrosion, and long-lasting performance. Their Copper Nickel 90/10 Bars are particularly sought after in marine, offshore, power generation, and chemical processing sectors. Thanks to their state-of-the-art manufacturing facilities and a talented workforce, Xuan Nickel Alloys guarantees reliable, cost-effective, and timely solutions for clients all over the world.
These Copper Nickel 90/10 Bars consist of 90% copper and 10% nickel, with carefully controlled amounts of iron and manganese added to boost their mechanical strength and corrosion resistance. They excel in resisting seawater, stress corrosion cracking, and biofouling, making them a dependable choice for challenging environments. In terms of mechanics, they boast a tensile strength ranging from 240 to 350 MPa, along with good yield strength and toughness, even in colder temperatures. With excellent ductility, weldability, and thermal stability, Copper Nickel 90/10 Bars promise long-term performance and structural integrity in demanding applications.
| Dimensions | DIN, EN, ASTM, JIS, ASME, BS, AISI |
|---|---|
| Round bar size | Diameter: 3-~800mm |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Billet Size | 1/2 to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Dimensions | Diameter / Height: |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
| Form | Rod, Round, Channel Bar, T-Bar, Flat Bar, Precision Ground Bar, Blocks, Square, Rings, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bar, Ingot, Billet, I/H Bar, Forging etc. |
| Grade | Element | |||||||
|---|---|---|---|---|---|---|---|---|
| Cu | 88.7 | |||||||
| Fe | 1.3 | |||||||
| Ni | 10.0 | |||||||
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength, ultimate | 303-414 MPa | 43900-60000 psi |
| Tensile strength, yield (depending on temper) | 110-393 MPa | 16000-57000 psi |
| Elongation at break (in 254 mm) | 42.00% | 42.00% |
| Machinability (UNS C36000 (free-cutting brass) = 100%) | 20% | 20% |
| Shear modulus | 52.0 GPa | 7540 ksi |
| Poisson’s ratio | 0.34 | 0.34 |
| Elastic modulus | 140 GPa | 20300 ksi |
At Xuan Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Bars in Da Nang, Vietnam, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Vietnam, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These bars are widely utilized in various industries that require both corrosion resistance and durability. In marine engineering, they play a crucial role in seawater piping systems, pumps, heat exchangers, and shipbuilding structures. Offshore oil and gas platforms rely on them for cooling water, firewater, and ballast systems, thanks to their resistance to seawater erosion. They are also used in desalination plants, power generation, and chemical processing facilities where strength and longevity are essential. Their reliability in harsh conditions makes Copper Nickel 90/10 Bars a vital component for both industrial and marine applications.
